2MP Outdoor IP Turret Camera

OE-C1016T2-S

2MP Outdoor IP Turret Camera

Equipped with analytics, the IP67-rated OE-C1016T2-S provides high quality images in a low-maintenance turret form factor.

Speak to Sales

Product Overview Video

OE-C1016T2-S 2MP Mini Turret Camera with Analytics

The OE-C1016T2-S is a 2-megapixel IP outdoor mini turret camera equipped with person, vehicle, and line-crossing detection analytics. The OE-C1016T2-S has a 2.8-millimeter, fixed lens, true wide dynamic range (WDR) and true day/night functionality that yields high-definition video. The low-maintenance turret housing and compact size make it well suited for installation in high-traffic areas, as well as areas that are difficult to access. Adaptive infrared (IR) technology prevents overexposure of objects close to the camera, further enhancing the low-light performance. Combine this compact camera with OpenEye Web Services to set real-time alerts and provide actionable insights.

overlay image

Capabilities

Key features of OE-C1016T2-S

2MP

2MP

Experience clear imagery with 2MP resolution, boosting your video quality.

Adaptive IR

Adaptive IR

Optimal illumination & clear images in low-light environments.

Product Details

Camera Specifications

Environment:
Outdoor
Maximum Resolution:
1920x1080
Maximum Framerate:
30FPS @ 1920x1080
Lens:
2.8mm Fixed Lens
Field of View:
106°
Pan/Tilt/Rotate:
Pan: 0° ~ 360° Tilt: 0° ~ 80° Rotate: 0° ~ 360°
Ingress Protection:
IP67
Impact Rating:
N/A
Alarm I/O:
N/A
Power Source:
PoE (IEEE 802.3af) / DC 12V±25%
Power Consumption:
Max 5W
Operating Temperature:
-22°F ~ 140°F (-30°C ~ 60°C)
Dimensions:
W: Ø4.4 x H: 3.7 (Ø110 x 94mm)
Weight:
0.93lb (0.42kg)
Certifications:
UL / cUL / FCC
Country Of Origin:
China
NDAA Compliant:
Yes

Technical Resources

Documentation

Software

Network Camera Manager:
2.7.0.15
OE-C1016T2-S-1 Camera Firmware:
IPC-B6202.5.82.C055146.L60.NB.260302

Documents

AE Spec:
OE-C1016T2 A&E Spec Sheet
Accessory Tree:
OpenEye Camera Accessories
Line Card:
Product Line Brochure
Quick Start Guide:
OE-C1016T2-S Quick Start Guide
Spec Sheet:
OE-C1016T2-S Spec Sheet
Technical Resource:
Country of Origin & NDAA Compliance
Technical Resource:
OE-C1016T2-S Revit & BIM Content
User Manual:
OE-C1016T2-S Hardware Manual
