OE-C9912M20

20MP Outdoor IP Multisensor Camera

With four 5MP lenses, deploy the remotely repositionable OE-C9912M20 camera in areas where one camera isn't enough.

Speak to Sales

Product Overview Video

OE-C9912M20 20MP Remotely Repositionable Multisensor Camera

The OE-C9912M20 is a 20MP outdoor, remotely PTZ repositionable, multisensor IP camera equipped with four, 5 Megapixel, 2.7~13.5mm VF, AF, Zoom lenses. Increase your return on investment with 360° coverage, equal to four single-sensor cameras, and simple installation through a single cable run.

overlay image

Capabilities

Key features of OE-C9912M20

IK10

IK10

Protect cameras from tampering & vandalism with an IK10 rating.

True Wide Dynamic Range

True Wide Dynamic Range

Quickly adapt to shifting light for consistent, high-quality imagery.

Remotely Repositionable

Remotely Repositionable

Adjust camera position remotely, ensuring optimal surveillance coverage.

Product Details

Camera Specifications

Environment:
Outdoor
Maximum Resolution:
2592x1944
Maximum Framerate:
30 FPS
Lens:
2.7 ~ 13.5mm, VF, AF, Motorized Zoom Lens
Field of View:
103° ~ 34°
Pan/Tilt/Rotate:
Remotely adjustable: Pan 360°, Tilt 90°, 4x Zoom
Ingress Protection:
IP66
Impact Rating:
IK10
Alarm I/O:
1 / 1
Power Source:
24VDC / 24VAC / IEEE 802.3bt PoE++ Class 5
Power Consumption:
Max. 40W
Operating Temperature:
-40°F ~ 131°F (-40°C ~ 55°C) (IR OFF)
Dimensions:
W: 13.9 x H: 13.9 x D: 11.6 (352 x 352 x 295mm)
Weight:
7.5lb (3.4kg)
Certifications:
UL / cUL / RCM / UKCA / FCC
Country Of Origin:
Taiwan
NDAA Compliant:
Yes

Technical Resources

Documentation

Software

Network Camera Manager:
OE-C9912M20-1 Camera Firmware:
